lesson 3.8.3 creating procedures

Using def to Create Reusable Blocks of Code

Welcome back, Systems Architects! Last lesson, you designed a professional blueprint (structure diagram) to fix the messy "Village" code and learnt how to draw structure diagrams using diagrams.net. Today, you are going to put on your hard hats and start building. We are going to learn how to turn those boxes on your diagram into real, working Python blocks called procedures. You'll learn how to teach the computer new words (commands) so that instead of copying and pasting code, you can just say

draw_widget()

and let the computer do the hard work!

Learning Outcomes

The Building Blocks (Factual Knowledge)

StateI have no idea what this means that the

def

keyword is used to define a procedure in Python.

IdentifyI have no idea what this means the body of a procedure by its indentation level.

DescribeI have no idea what this means the difference between defining a procedure and calling it.

The Connections and Theories (Conceptual Knowledge)

ExplainI have no idea what this means how procedures are used to implement the decomposition planned in a structure diagram.

ExplainI have no idea what this means that using a procedure is a form of abstractionWhere unecessary detail is removed from a problem to make it easier to solve. where the implementation details are hidden.

AnalyseI have no idea what this means the benefits of code reusability for maintenance and efficiency.

The Skills and Methods (Procedural Outcomes)

WriteI have no idea what this means a simple, self-contained procedure to solve a single sub-problem (A.1.7).

RefactorI have no idea what this means a monolithic block of code by moving distinct sub-tasks into separate procedures (A.4.7.1).

Digital Skill Focus: Use a text editor with syntax highlighting to write a simple program (A.4.2).

Teaching the Computer New Tricks

In our previous lessons, we saw that writing one long list of instructions (Monolithic Code) is messy. It's hard to read, hard to fix and repetitive.

We fixed the plan by creating a Structure Diagram. Now we need to fix the code.

In Python, we can group a set of instructions together and give them a name. This is called a ProcedureType of subroutine which may take parameters but returns no value. Used to structure code.. Think of it like teaching the computer a new trick. Once you teach it how to

draw_widget()

, you can ask it to do that trick whenever you want just by asking it!

The Syntax of a Procedure

To create a procedure, we use the keyword

def

(short for define).

def procedure_name():
  # Code goes here.
  # Must be indented!

Here is the "Recipe" for a procedure:

Define: Start with

def

Name: Give it a sensible name (using snake_case).

Parentheses: Add brackets

()

Colon: End the line with a colon

Indentation: All the code that belongs to the procedure MUST be indented (moved to the right).

Task 1 Starry, Starry Night?

So, it's simple to get Python turtle to draw a square but what if I wanted to draw a hundred squares or I wanted it to draw a thousand squares and I wanted each one to have a random colour and be drawn at a random position on the turtle canvas and...

Get Organised

Download the shape-sketcher.py script and make sure it's saved somewhere safe.

Open it with Thonny (other IDEs are available) but DON'T run it yet.

Organise your workspace!

PRIMM!

PREDICT

Do not run the code yet. Read through the script on your screen and discuss the following questions with your partner and write the answers on your whiteboard (if you have one).

Look at the list

["red", "green", "blue", "pink", "yellow"]

. What do you think the computer uses this for?

Look at the line

for i in range(100):

. How many times will the code inside this loop run?

There is a function called

draw_square()

. Can you describe how it works?

If you have a whiteboard, sketch what you think the final screen will look like.

RUN

Now, run the script (press F5 or click the green 'play' button). Watch the animation carefully. Did the output match your prediction? What happens if you run the program a second time? Is the picture exactly the same?

INVESTIGATE

Answer these questions to understand how the code works. You will need to look closely at specific lines.

The Grid: Look at

x = random.randint(-200,200)

. What happens if you change the numbers to

(-50, 50)

? (Think about where the squares would appear).

The Pen: Why do we use

t.penup()

before

t.goto(x,y)

inside the main loop? What would happen if we commented that line out (put a

in front of it)? Why not try it?

The Logic:

Line 15 says

for i in range(4):

. What does this loop control?

Line 23 says

for i in range(100):

. What does this loop control?

The Procedure: Why do we put the instructions to draw a square inside

def draw_square():

rather than typing them out 100 times? What's the point?

MODIFY

Now let’s change the code to make it our own. Complete these challenges in order.

Bronze (Aesthetics): Change the list of colors. Add "orange", "purple", and "black". Remove "yellow". Run the code again. Like what you see?

Silver (Geometry): Change the code so that the squares are larger, e.g. have a side length 50 instead of 20. How does this look?

Gold (Logic): Change the

draw_square

function so that it draws a triangle instead of a square. Hint: A triangle has 3 sides. The angle turn will be 120, not 90.

Platinum (Boundaries): Change the code so that it draws 500 shapes, but spreads them out over a larger area (try coordinates -400 to 400). You might also want to speed up the drawing - see if you can work out how.

MAKE

Using the code you have just learned, create a new script to create a scene that looks like a night sky.

Create a new script and save it as starry-night.py in a safe place.

Set the background color to black (Use the instruction

screen.bgcolor("black")

after you have created the

screen

.).

Create a procedure called

draw_star()

def draw_star():
  color = random.choice(["yellow", "white"])
  t.color(color)
  t.fillcolor(color)
  t.pendown()
  t.begin_fill()
  for i in range(5):
      t.forward(20)
      t.left(144)
  t.end_fill()
  t.penup()

Use this procedure to draw 50 stars scattered randomly across the screen.

Outcome: I have predicted what will happen when I run a Python script. I may even have drawn a lovely picture of a starry night...

From Blueprint to Bricks

So, in the first lesson of this module, we saw some monolithic code designed to draw just three houses. I think now, we are in a position to do a little better and maybe even draw a village!

Task 2 The Village Vision

Before we start, we need to break down our problem using a structure diagram so we can identify the different procedures we need to design.

The main goal (Level 0) is to draw a village.

To do this, we need to draw a cottage (Level 1) more than once.

We design a

draw_cottage()

procedure which repeats, say, 10 times.

Each cottage can be structurally decomposed to a wall and a roof.

We design a

draw_wall()

procedure to draw the wall.

We design a

draw_roof()

procedure to draw the roof.

Get Organised!

Download the village-vision.py script and make sure it's saved in a safe place.

Open the script in Thonny (other IDEs are available).

Organise your workspace.

Tell Python how to draw a wall

Copy this procedure definition and paste it into the correct place in the template (on Line 9).

def draw_wall():
  color = random.choice(["skyblue", "purple", "forestgreen"])
  t.color(color)
  t.fillcolor(color)
  t.pendown()
  t.begin_fill()
  for i in range(4):
      t.forward(20)
      t.left(90)
  t.end_fill()
  t.penup()

Tell Python how to draw a roof

Copy this procedure definition and paste it into the correct place in the template (probably on Line 22).

def draw_roof():
  color = random.choice(["slategrey","gold","seagreen"])
  t.color(color)
  t.fillcolor(color)
  t.pendown()
  t.begin_fill()
  for i in range(3):
      t.forward(20)
      t.left(120)
  t.end_fill()
  t.penup()

Tell Python how to draw a cottage

Copy this procedure definition and paste it into the correct place in the template (probably on Line 35).

def draw_cottage():
  draw_wall()
  t.goto(t.xcor(),t.ycor()+20)
  draw_roof()

Let's get building!

So, we're ready to build our village... Just press ▶ PLAY!

Outcome: I have refactored a monolithic script into a modular program using a reusable procedures.

Why did we do this?

By using procedures, we have achieved Abstraction. We have hidden the complex details of how to draw a cottage inside the procedure. The main part of our program is now just a simple list of commands: "Go here, draw a cottage, go there, draw a cottage"...

This makes our code:

Readable: Humans can understand what

draw_wall()

draw_roof()

and

draw_cottage()

mean.

Maintainable: If we want to change the roof colour to green, we only have to change it in one place (inside the definition), and every house will update automatically!

Today you have learnt that Procedures are reusable blocks of code that allow us to implement the decomposition we planned in our diagrams, making our software cleaner and easier to manage.
